Drivetrain
| Clutch | Wet multiplate with coil springs |
| Gearbox | 6-speed |
| Transmission | |
| Transmission Type | Chain (final drive) |
| Chain Type | 2.379:1 |
| Gear Ratios 1st | 10.169:1 |
| Gear Ratios 2nd | 6.933:1 |
| Gear Ratios 3rd | 5.151:1 |
| Gear Ratios 4th | 4.105:1 |
| Gear Ratios 5th | 3.508:1 |
| Gear Ratios 6th | 3.017:1 |
Suspension
| Front Suspension | Dual A-Arm with Stabilizer Bar and 20.5 in (52.07 cm) Usable Travel |
| Rear Suspension | Trailing Arm with Stabilizer Bar and 20 in (50.8 cm) Usable Travel |
| Front Shocks | 2" Walker Evans Needle Shocks with 16-Position Adjustable Clickers |
| Rear Shocks | 2.5" Walker Evans Needle Shocks with 16-Position Adjustable Clickers |
| Front Travel | 16 in (406 mm) |
| Rear Travel | 18 in (457 mm) |
Brakes
| Front Braking System | 4-Wheel Hydraulic Disc with Dual-Bore Front and Single Bore Rear Calipers |
| Rear Braking System | 4-Wheel Hydraulic Disc with Dual-Bore Front and Single Bore Rear Calipers |
| Parking Brake | Park In-Transmission |
Tires
| Wheels | Cast Aluminum |
| Front Tire | Trail Master X/T 2.0, 30 x 10-14 Radial Tire |
| Rear Tire | Trail Master X/T 2.0, 30 x 10-14 Radial Tire |
| Front Wheel | 10-Spoke Machined Cast 19 in x 3.5 in |
| Rear Wheel | 10-Spoke Machined Cast 16 in x 5 in |
Dimensions
| Overall Vehicle Size | 28" w x 43.3" h |
| Rake / Trail | 25° / 5.9" |
| Wheelbase | 90 in (2,286 mm) |
| Seat Height | 31.6 in |
| Ground Clearance | 14.5 in (368 mm) |
| Lean Angle (Left) | 31 |
| Lean Angle (Right) | 31 |
| Bed Box Dimensions | 28 x 22 x 7 in (72.0 x 57.0 x 17.8 cm) |
Capacities
| Fuel Capacity | 9.5 gal (36 L) |
| Hitch Type | Rear: Receiver |
| Cargo Capacity | 298 lbs (656 kg) |
| Payload Capacity | 336 lbs (740 kg) |
| Storage Capacity | 0.16 gal (0.6 L) |
| Towing Capacity | 181 lbs (400 kg) |
| Bed Capacity | 1,500 lbs. (680 kg) |
| Hitch Capacity | 3,500 lbs. (1588 kg) |
| Cargo System | Lock & Ride |
| Box Capacity | 300 lb (136 kg) |
| Seating Capacity | 0 |
Weights
| Dry Weight | 1,642 lbs (745 kg) |
Electronics
| Gauges | Fairing-mounted instrument cluster featuring analog speedometer and tachometer with fuel gauge, range, odometer and current gear. 15 LED telltale indicators; cruise control enabled, cruise control set, neutral, high beam, turn signal, ABS, check engine, low tire pressure, battery, low fuel, security system, low engine oil pressure and MPH or km/h unit designation. |
| Magneto | 650-W |
| Audio System | Includes 4 Standard 50 watt speakers. 2 in the fairing, 2 in the trunk. 200 watts total. |
Lights & Safety
| Warranty | One year. Transferable. Unlimited-mileage. |
| Steering | Standard Tilt & Telescoping |
| Cage Type | Profiled cage ROPS approved |
| Lighting | LED Head Lights & Tail Lights, Front & Rear LED Accent Lights, Illuminated In-Cab Controls |
| Instrumentation | RIDE COMMAND 7 Glove-Touch Display: Digital Instrumentation, Built-In GPS, Group ride (cell-based or GPS based), Topographic Mapping, Bluetooth & USB Smartphone Connectivity, AM/FM & Weather Radio, In-Vehicle Communications Capable With Optional Sena Headsets Speedometer, Odometer, Tripmeter, Tachometer, Coolant Temperature, Volt Meter, Hour Meter, Service Indicator, Clock, Gear Indicator, Fuel Gauge, Hi-Temp Light, Seatbelt Reminder Light, Fault Code Display, DC Outlet, Ambient Temp, Rockford Fosgate Stage 3 Audio (Including 2 Front & 2 Rear Co-axial Speakers and External 400W Amp) |
| Features | Doors: Full Doors | Other Standard: Color Matched Seats, Premium Paint & Graphics, Color-Matched Dash & Bumper, 900-W Charging System, 6-Position Pulse Bar, Tilt Steering, Poly Sport Roof, Rockford Fosgate Stage 3 Audio, Ride Command, Rear Camera, Accent Lighting, Adjustable 4-Point Subzero Harnesses, Front Tow Loop, Front Bumper |
