Drivetrain
| Transmission | |
| Clutch | Automatic |
| Chain Type | #520 chain; 14T/40T |
| Gear Ratios 1st | 10.549:1 |
| Gear Ratios 2nd | 7.170:1 |
| Gear Ratios 3rd | 5.715:1 |
| Gear Ratios 4th | 4.850:1 |
| Gear Ratios 5th | 3.680:1 |
| Gear Ratios 6th | 0.966 : 1 |
| Gearbox | 5-speed |
| Transmission Type | Chain (final drive) |
Suspension
| Front Suspension | Dual A-Arm with Stabilizer Bar and 20.5 in (52.07 cm) Usable Travel |
| Rear Suspension | Trailing Arm with Stabilizer Bar and 20 in (50.8 cm) Usable Travel |
| Front Shocks | 2" Walker Evans Needle Shocks with 16-Position Adjustable Clickers |
| Rear Shocks | 2.5" Walker Evans Needle Shocks with 16-Position Adjustable Clickers |
| Front Travel | 16 in (406 mm) |
| Rear Travel | 18 in (457 mm) |
Brakes
| Front Braking System | 4-Wheel Hydraulic Disc with Dual-Bore Front and Single Bore Rear Calipers |
| Rear Braking System | 4-Wheel Hydraulic Disc with Dual-Bore Front and Single Bore Rear Calipers |
| Parking Brake | Park In-Transmission |
Tires
| Wheels | Cast Aluminum |
| Front Tire | Trail Master X/T 2.0, 30 x 10-14 Radial Tire |
| Rear Tire | Trail Master X/T 2.0, 30 x 10-14 Radial Tire |
| Front Wheel | Machined Highlights 16 in x 3.5 in |
| Rear Wheel | Machined Highlights 16 in x 3.5 in |
Dimensions
| Overall Vehicle Size | 48.5" w x 49" h |
| Wheelbase | 90 in (2,286 mm) |
| Seat Height | 26.6 in (676 mm) |
| Ground Clearance | 14.5 in (368 mm) |
| Bed Box Dimensions | 28 x 22 x 7 in (72.0 x 57.0 x 17.8 cm) |
| Rake / Trail | 32° / 4" |
| Lean Angle (Left) | 33 |
| Lean Angle (Right) | 33 |
Capacities
| Storage Capacity | 2.5 gal (9.4 L) |
| Towing Capacity | 1,134 lbs (2,500 kg) |
| Fuel Capacity | 9.5 gal (36 L) |
| Rack Capacity | 200 lb (91 kg) with LinQ quick-attach |
| Bed Capacity | 900 pounds |
| Cargo Capacity | 454 lbs (1,000 kg) |
| Seating Capacity | 0 |
| Hitch Type | Rear: Standard |
| Payload Capacity | 336 lbs (740 kg) |
| Hitch Capacity | 1,500 lb (680 kg) |
| Cargo System | Lock & Ride |
| Box Capacity | 300 lb (136 kg) |
| Rack Capacity (Front) | 120 lb (55 kg) |
| Rack Capacity (Rear) | 240 lb (110 kg) |
Weights
| Dry Weight | 1,642 lbs (745 kg) |
Electronics
| Gauges | Standard: Analog speedometer, digital tachometer, odometer, trip meter, engine temp, low fuel lamp, etc. Limited: Standard features + cruise control, traction control, three ride modes, and USB charger. Limited +Tech: Limited features + 4" Display powered by RIDE COMMAND and RIDE COMMAND+ Telecommunications Unit (TCU). |
| Magneto | 850-W |
| Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
Lights & Safety
| Steering | Tilt: Standard Tilt |
| Lighting | LED Head Lights & Tail Lights, Front & Rear LED Accent Lights, Illuminated In-Cab Controls |
| Instrumentation | RIDE COMMAND 7 Glove-Touch Display: Digital Instrumentation, Built-In GPS, Group ride (cell-based or GPS based), Topographic Mapping, Bluetooth & USB Smartphone Connectivity, AM/FM & Weather Radio, In-Vehicle Communications Capable With Optional Sena Headsets Speedometer, Odometer, Tripmeter, Tachometer, Coolant Temperature, Volt Meter, Hour Meter, Service Indicator, Clock, Gear Indicator, Fuel Gauge, Hi-Temp Light, Seatbelt Reminder Light, Fault Code Display, DC Outlet, Ambient Temp, Rockford Fosgate Stage 3 Audio (Including 2 Front & 2 Rear Co-axial Speakers and External 400W Amp) |
| Warranty | 1 Year (Limited Factory Warranty) |
| Features | Doors: Full Doors | Other Standard: Color Matched Seats, Premium Paint & Graphics, Color-Matched Dash & Bumper, 900-W Charging System, 6-Position Pulse Bar, Tilt Steering, Poly Sport Roof, Rockford Fosgate Stage 3 Audio, Ride Command, Rear Camera, Accent Lighting, Adjustable 4-Point Subzero Harnesses, Front Tow Loop, Front Bumper |
| Cage Type | Dual-phase 980 steel |
| Handlebars | Aluminum |
