Drivetrain
| Transmission | |
| Clutch | |
| Chain Type | 2.379:1 |
| Transmission Type | Belt |
| Gearbox | 5-speed |
| Gear Ratios 1st | 10.169:1 |
| Gear Ratios 2nd | 6.933:1 |
| Gear Ratios 3rd | 5.151:1 |
| Gear Ratios 4th | 4.105:1 |
| Gear Ratios 5th | 3.508:1 |
| Gear Ratios 6th | 3.017:1 |
Suspension
| Front Suspension | Dual A-Arm |
| Rear Suspension | Dual Arched A-Arm IRS |
| Front Shocks | Walker Evans 2.5 Velocity Needle Shock with 16-Position Adjustable Clickers |
| Rear Shocks | Walker Evans 3.0 Velocity Needle Shock with 16-Position Adjustable Clickers |
| Front Travel | 4.9 in (125 mm) |
| Rear Travel | 4.9 in (125 mm) |
Brakes
| Front Braking System | Foot activated and power assisted, 4 wheel hydraulic disc with dual-bore front and rear calipers |
| Rear Braking System | Foot activated and power assisted, 4 wheel hydraulic disc with dual-bore front and rear calipers |
| Parking Brake | Park In-Transmission |
Tires
| Wheels | 15" Aluminum |
| Front Tire | 30 x 10-15; KENDA CROSS TRAIL | 8 Ply Rated |
| Rear Tire | 30 x 11-15; KENDA CROSS TRAIL | 8 Ply Rated |
| Front Wheel | 10-Spoke Machined Cast 19" x 3.5" |
| Rear Wheel | 10-Spoke Machined Cast 16" x 5" |
Dimensions
| Overall Vehicle Size | 28" w x 43.3" h |
| Wheelbase | 127 in (3,226 mm) |
| Ground Clearance | 15 in (380 mm) |
| Rake / Trail | 26° / 7" |
| Seat Height | 26.4 in |
| Bed Box Dimensions | 43.4 x 56 x 13.4 in (110.2 x 142.2 x 34 cm) |
| Lean Angle (Left) | 31 |
| Lean Angle (Right) | 31 |
Capacities
| Storage Capacity | 3.1 gal (11.7 L) |
| Fuel Capacity | 13.6 gal (51.5 L) |
| Rack Capacity | Front: 120 lb (54.4 kg) / Rear: 240 lb (109 kg) |
| Hitch Type | Standard 2 in (5 cm) Receiver |
| Towing Capacity | 1,134 lbs (2,500 kg) |
| Rack Capacity (Front) | 90 lb (40.8 kg) |
| Rack Capacity (Rear) | 180 lb (81.6 kg) |
| Cargo System | Lock & Ride MAX |
| Payload Capacity | 755 lbs (1,665 kg) |
| Box Capacity | 1,500 lbs. (680 kg) |
| Seating Capacity | 6 |
| Cargo Capacity | 454 lbs (1,000 kg) |
| Hitch Capacity | 3,500 lbs. (1588 kg) |
| Bed Capacity | 1,500 lbs. (680 kg) |
Weights
| Dry Weight | 3,323 lbs (1,507 kg) |
Electronics
| Gauges | Fairing-mounted instrument cluster featuring analog speedometer and tachometer with fuel gauge, range, odometer and current gear. 15 LED telltale indicators: cruise control enabled, cruise control set, neutral, high beam, turn signal, ABS, check engine, low tire pressure, battery, low fuel, security system, low engine oil pressure and MPH or km/h unit designation. |
| Magneto | 650 W |
| Audio System | Upgraded PowerBand 2.0 Audio package Includes: 2 - 100 watt fairing speakers, 2 - 100 watt saddlebag speakers. 400 watts total. |
Lights & Safety
| Steering | Tilt & Telescoping |
| Cage Type | Profiled cage, ROPS approved |
| Features | Premium Pro Shield Cab, Doors with Full Power Windows, Tipout Glass Windshield with Wiper, Rear Glass Panel, Dome Light, Door Puddle Lighting, Interior Accent Lighting, Rearview Mirror, Heat, AC, Defrost. Premium Heated Front Contoured Seats with Additional Bolstering, Premium Headrests and Center Armrest. Premium, Telescoping Steering Wheel and Painted Interior Accents. Polaris Pulse Electrical System (6 position), 140 Amp Charging System. Front Bumper with D-Rings, Top Bar and Integrated LED Auxillary Lights. Overhead Switch Panel, DC Outlet, USB Charge Port, Trickle Charger, 12V Cargo Box Power Port, NorthStar Badge, Polaris Pro HD 6,000 lb. Synthetic Rope Winch with Autostop and Rapid Rope Recovery plus Wireless Remote |
| Lighting | LED Headlights |
| Instrumentation | 7 Display Powered by RIDE COMMAND: Plow Mode, Group Ride, GPS Navigation, Bluetooth, AM/FM Radio; Factory Rear Camera; Driver Forward Information Center w/ 4 in Color Display + Analog Speedometer & Tachometers: User Selectable Blue/Red Backlighting & Brightness, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Oil Pressure, Transmission Indicator, EPS Indicator, Voltmeter, Service Indicator and Codes, Seat Belt Reminder, Speed Limiting |
| Warranty | 1 Year (Limited Factory Warranty) |
| Handlebars | Neken, aluminium 28/22 mm |
