Drivetrain
| Transmission | Automatic PVT P/R/N/L/H |
| Chain Type | 2.276:1 |
| Clutch | Wet, Multi-Plate |
| Gear Ratios 1st | 2.769:1 |
| Gear Ratios 2nd | 1.882:1 |
| Gear Ratios 3rd | 1.500:1 |
| Gear Ratios 4th | 1.273:1 |
| Gear Ratios 5th | 1.125:1 |
| Gear Ratios 6th | 0.966:1 |
| Gearbox | 4-speed |
| Transmission Type | Belt (final drive) |
Suspension
| Front Suspension | Light Weight Boxed Dual A-Arm with 3 Piece Stabilizer Bar and 27" (68.6 cm) Usable Travel, 22.25" (56.5 cm) Wheel Travel, Unitized Hubs |
| Rear Suspension | Tubular Trailing Arm with Boxed Gusseting and Toe Link, and Stabilizer Bar and 28.3 in (71.9 cm) *Usable Travel, 22.4 in (56.9 cm) Wheel Travel, Unitized Hubs |
| Front Travel | 18.6 in (472 mm) |
| Rear Travel | 21.1 in (536 mm) |
| Front Shocks | Walker Evans 2.5 Velocity Needle Shock with 16-Position Adjustable Clickers |
| Rear Shocks | Walker Evans 3.0 Velocity Needle Shock with 16-Position Adjustable Clickers |
Brakes
| Front Braking System | 4-Wheel Hydraulic Disc with Triple-Bore |
| Rear Braking System | 4-Wheel Hydraulic Disc with Dual-Bore Calipers |
| Parking Brake | Park In-Transmission |
Tires
| Wheels | 15" Cast Aluminum Rim with 5-Lug Pattern |
| Front Tire | 32 x 10-15 Maxxis Rampage Fury; 8-Ply Rated; Wheel Size 15x7 |
| Rear Tire | 32 x 10-15 Maxxis Rampage Fury; 8-Ply Rated; Wheel Size 15x7 |
| Front Wheel | Cast 8-Spoke 19" x 3.5" |
| Rear Wheel | Cast 8-Spoke 16" x 3.5" |
Dimensions
| Overall Vehicle Size | 62.5" w x 79.6" h |
| Wheelbase | 96 in (2,440 mm) |
| Ground Clearance | 16 in (406 mm) |
| Bed Box Dimensions | 26 x 17.7 x 11.5 in (66 x 45 x 29.2 cm) |
| Rake / Trail | 29° / 4.8" |
| Seat Height | 25.7 in (654 mm) |
| Lean Angle (Left) | 33 |
| Lean Angle (Right) | 33 |
Capacities
| Cargo System | Lock & Ride |
| Payload Capacity | 331 lbs (730 kg) |
| Fuel Capacity | 12 gal (45.4 L) |
| Box Capacity | 300 lb (136 kg) |
| Hitch Type | Standard 1.25 in (3.2 cm) Receiver |
| Hitch Capacity | 2,500 lb (1,134 kg) |
| Bed Capacity | 1000 pounds (49 states) |
| Storage Capacity | 16.9 gal (63.9 L) |
| Towing Capacity | 1,134 lbs (2,500 kg) |
| Rack Capacity | Front: 100 lb (45 kg) / Rear: 700 lb (318 kg) |
| Seating Capacity | 0 |
| Rack Capacity (Front) | 33 pounds |
| Rack Capacity (Rear) | 66 pounds |
| Cargo Capacity | 454 lbs (1,000 kg) |
Weights
| Dry Weight | 2,024 lbs (918 kg) |
Electronics
| Gauges | Standard and Limited: Analog speedometer, Digital tachometer, odometer, trip meter, engine temp, low fuel lamp Limited +Tech: Digital Speedometer, Digital Tachometer, Odometer, fuel gauge, compass, ambient temperature, Gear indicator |
| Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
| Magneto | 650-W |
Lights & Safety
| Steering | Power: Rack Mounted High Assist Electronic Power Steering with Quick Turn Rack; Race Inspired Steering Wheel; RIDE COMMAND Push Button Controls |
| Features | Doors: Vented Full Doors | Other Standard: High Output 900W Charging System with Sealed Electrical, Polaris Pulse System, In-Dash Charge Port, Polaris P.A.S.S. |
| Lighting | Signature White LED Low/High Beam Headlights, Red LED Tail / Brake Lights, Interior Footwell Lights |
| Instrumentation | Dual-sweep Analog Dials w/ 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, Front and Rear DC Outlet, Polaris P.A.S.S Anti-Theft System |
| Warranty | Factory: 2 Years, Unlimited Miles |
| Cage Type | Profiled cage. ROPS approved |
| Handlebars | Aluminium, tapered 28/22 mm |
